Exchange 2016 Hybrid Deployment Check Fails

By January 7, 2019September 18th, 2020Blog, Exchange
Exchange Server 2016 Hybrid Deployment Fail Solutions

Have you ever run the Hybrid Deployment Check and received any of the following errors?

Exchange Server 2016 Deployment Check Fail screenshot

A hybrid deployment with Office 365 has been detected. Please ensure that you are running setup with the /TenantOrganizationConfig switch. To use the TenantOrganizationConfig switch you must first connect to your Exchange Online tenant via PowerShell and execute the following command: “Get-OrganizationConfig | Export-Clixml -Path MyTenantOrganizationConfig.XML”. Once the XML file has been generated, run setup with the TenantOrganizationConfig switch as follows “/TenantOrganizationConfig MyTenantOrganizationConfig.XML”.

If you continue to see this this message then it indicates that either the XML file specified is corrupt, or you are attempting to upgrade your on-premises Exchange installation to a build that isn’t compatible with the Exchange version of your Office 365 tenant. Your Office 365 tenant must be upgraded to a compatible version of Exchange before upgrading your on-premises Exchange installation.

The parameter ‘TenantOrganizationConfig’ is not valid for current operation ‘PrepareSchema’. Setup checks failed: Invalid command line arguments.

Could not load type ‘Microsoft.Exchange.Data.SubscribedPlanDetails’ from assembly ‘Microsoft.Exchange.Data, Version=15.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35’.

I’ve hit this issue a few times, let’s review the two solutions that have led to success for me.

Solution 1:

Run the following in an administrative command prompt:

Setup.exe /PrepareAD /TenantOrganizationConfig MyTenantOrganizationConfig.xml /IAcceptExchangeServerLicenseTerms

Note In this scenario, schema extension is performed implicitly by running the /PrepareAD switch. Therefore, to complete these steps, you must have Schema Admin rights to perform the schema changes in addition to the rights that are necessary to perform the /PrepareAD steps.

Solution 2:

If you’re running Exchange RTM upgrade to the lastest CU from the following link.

https://docs.microsoft.com/en-us/Exchange/new-features/updates?view=exchserver-2019



Hybrid Configuration Check Finished Message

Looking for other Exchange Hybrid Deployment Check Fails and Fixes? Read about getting past a “username or password is invalid” error on our blog!

Brandon Stuart, PEI
